Evolution S355CPS 355mm Metal Cutting Chop Saw With TCT Blade (Refurbished - Like New)
Offering finish quality cuts straight off the blade that are cold enough to handle and ready to weld, the S355CPS 355mm chop saw is a firm favourite with metal fabricators, welders and makers of all kinds. Built for heavy, hard cuts the S355CPS chop saw offers speed, precision and repeatability cut after cut.
Accessory blades designed specifically for Aluminium, thin steel, stainless steel and diamond cutting discs are available to fit the S355CPS. If you need a trade trusted tool to get the job done then why not add the S355CPS mild Steel cutting chop saw to your arsenal?
- Heavy-duty cast aluminium base with integrated wear plate & bench mounting holes.
- Quick-release vice with robust square-threaded rod for fast & secure clamping.
- Accurate & durable cast steel vice with 0° - 45° mitre capacity & locking pin.
- Compact design with a head lock down pin & carry handle for easy transportation.
- Chip collection tray for a cleaner, safer working environment.
- Ergonomic, ambidextrous trigger with comfortable textured grip.
- Attachable ‘v’ shape block included for secure clamping of round & square tube.
- Easy blade change with integrated tool storage.
Specifications
| Motor (240V 50Hz): | 2200W |
| Motor (110V 50Hz): | 1600W |
| Speed No Load: | 1550 min-1 |
| Max. Bevel (Left): | 45° |
| Cable Length: | 3m |
| Blade Dia.: | 355mm |
| No. of Teeth: | 66 |
| Bore: | 25.4mm / 1 In. |
| Kerf: | 2.4mm |
| Mild Steel Plate (Max Thickness): | 12mm |
| Stainless Steel Plate (Max Thickness): | 5mm |
| Square Tube at 90° (Mild Steel): | 120 x 120mm |
| Square Tube at 45° (Mild Steel): | 89 x 89mm |
| Rectangle Tube at 90° (Mild Steel): | 95 x 180mm |
| Rectangle Tube at 45° (Mild Steel): | 78 x 110mm |
| Round Tube at 90° (Mild Steel): | Ø 130mm |
| Round Tube at 45° (Mild Steel): | Ø 105mm |
| Minimum Cut Off Piece Length: | 8 mm |
| Packaging Dimensions: | 470 x 575 x 374mm |
| Product Dimensions: | 410 x 530 x 310mm |
| Product Weight: | 23.1 kg |
| Packaged Weight: | 27 kg |
| Sound Pressure Level LPA: | 94.9 dB(A) K:3dB(A) |
| Sound Power Level LWA: | 107.9 dB(A) K=3 dB(A) |
Items Supplied
| 66 Tooth Mild Steel TCT Blade |
| Hex Key 8mm (Blade Change) |
| V-Block |
